Pytes V5°α Plus is a high-performance 51.2V 5.12kWh LiFePO₄ battery module, purpose-built for home and small business energy storage needs. Designed for rack-mounted installations, this battery features advanced BMS protection, fire suppression, remote monitoring, and easy parallel scalability — from a single unit to large capacity setups. Whether you're going off-grid, using solar backup, or enhancing self-consumption, V5°α Plus provides long-lasting power, industry-grade safety, and plug-and-play expansion.

Battery ModelV5°α Plus
Electrical
ChemistryLFP
Nominal Voltage51.2V
Nominal Energy47.5V~57.6V
Voltage Range100Ah
Recommended Charge/Discharge Current[1]75A
Max Continuous Charge/Discharge Current[2]75A
Peak Charge/Discharge Current

101A~120A (3min);
121A~180A (15sec)

Integrated BreakerDC 125V/125A
General
Connection Options

Amphenol SurLok Plus 8.0mm

ChemistryLFP
Communication ProtocolCAN/RS485

Dimensions(L x W x H)

484*578.2*140mm/19.05*22.76*5.51inch(3.2U)
Weight45.34kg/100lbs
Ambient Temperature-10°C~50°C/14°F~122°F
Round-Trip Efficiency≥95%
Cycle Life*≥6000 cycles
Warranty10 Years
Mounting MethodWall / Ground (W/ Optional Battery Tray)


Add-on Functionalities
WIFI ConnectionRemote monitoring and upgrade
Heating Pad

Temperature Rise: 10°C/h / 18°F/h
Operation Temperature: -18°C~10°C/-0.40°F~50°F

Scalability16 pcs (81.92kWh) in a group

6 groups (491.52kWh) in a system w/a Hub


Certifications
UL9540 Ed.2 (2020), UL9540A, UL1973, CEC, SGIP, CE, IEC62619, UN38.3
